//*******************The Log class
import java.io.BufferedWriter;
import java.io.File;
import java.io.FileWriter;
import java.io.IOException;
import java.uitl.Date;
import java.text.DateFormat;

public class Log{
   private static final String filePath = PropertyReader.getResource("Log_File_Path");//Supposing we have define in the last ProperyReader class and the file

   public static final String EXCEPTION                  =   "Exception";
   public static final String CREATE_STAFF           =   "Create Staff";
   public static final String EDIT_STAFF                 =   "Edit Staff";
   public static final String DELETE_STAFF            =   "Delete Staff";
   public static final String RECORD_HAS_EXIST  =   "Record Has Exist";

   public static void log(String msg_type, Exception e){
      StringBuffer errMsg = new StringBuffer(e.toString);

      for(int i=0;i<e.getStackTrace().length;i++){
         errMsg.append("\n\t at");
         errMsg.append(e.getStackTrace()[i].toString);
      }
      log(msg_type,errMsg.toString());
      OptionPanel.showErrMsg("Sorry,System may have an error \n System will exit");
      System.exit(-1);
   }

  public static void log(String msg.type,Staff staff){
     String msg = null;
     if(msg_type == CREATE_STAFF){
         msg = staff.toString() + "has benn created";
     }else if(msg_type == EDIT_STAFF){
         msg = staff.toString() + "has been Changed";
     }else if(msg_type == DELETE_STAFF){
         msg = staff.toString() + "has been Deleted";
     }else if(msg_type == RECORD_HAS_EXIST){
         msg = staff.toString() + "has exist in the database";
     }
     log(msg_type,msg);
  }

  private static void log(String msg_type,String msg){
      BufferedWriter out = null;
      DateFormat df = DateFormat.getDateInstance(DateFormat.MEDIUM);

      try{
        out = new BufferedWriter(new FileWriter(getLogFilePath(),true));//如果為 true，則將字節寫入文件末尾處，而不是寫入文件開始處
        out.write("["+df.format(new Date()) + "] <" + msg_type + "> :" + msg);
        out.newline();
        out.newline();
      }catch(IOException e){
          e.printStackTrace();
      }finally{
         try{
           if(out!=null){
              out.close();
           }
         }catch(IOException e){
            e.printStackTrace();
         }
      }
  }

  private static String getLogFilePath(){
     File logDir = new File(filePath);
     if(!logDir.exists()){
       logDir.mkdir();
     }

     int i = 1;
     String fileName = filePath + "log_";
     File file = new File(fileName + i + ".txt");

     while(file.exists() && file.length() > 30000L) {
         i++;
         file = new File(fileName + i + ".txt");
     }

      return fileName + i + ".txt"
  }
}

//*****************************The OptionPanel Dialog Class for the Log Class
import javax.swing.JOptionPane;

public class OptionPanel {
   private static final String appTitle = PropertyReader.getResource("App_Title");//suposing the file has been established and the property app-title stands for the name of application
   private static final MainFrame frame = MainFrame.getMainFrame();

   public static void showWarningMsg(String msg){
      JOptionPane.showMessageDialog(frame,msg,appTitle,JOptionPane.WARNING_MESSAGE);
   }
   public static void showErrMsg(String msg){
       JOptionPane.showMessageDialog(frame,msg,appTitle,JOptionPane.Error_MESSAGE);
   }
   public static int showConfirmMsg(String msg){
        return JOptionPane.showConfirmDialog(frame,msg,appTitle,JOptionPane.YES_NO_OPTON,JOptionPane.QUESTION_MESSAGE);
   }
}

In a project, we can write a class to read the properties.As following,

import java.io.InputStream;
import java.io.IOException;
import java.util.Properties;

public class PropertyReader{
   private static Properties property = null;

   static{
      InputSteam stream = null;
      try{
        stream=PropertyReader.class.getResourceAsStream("/resource/properties.properties");
        property = new Properties();
        property.load(stream);
      }catch(IOException e){
          e.printStackTrace();
      }finally{
          if(stream != null){
             try{
                stream.close();
             }catch(IOException e){
                e.printStackTrace();
             }
          }
      }
   }
   public static String getResource(String key){
     if(property == null){
       return null;// init error;
     }

     return property.getProperty(key);
   }
}

Most developers have heard of, and possibly used, scripting languages such as Ruby, JavaScript, and Python. These dynamic languages are enjoying a resurgence in popularity, largely because of their flexibility and simplicity, and the productivity gains they promise.

Java 6 comes with built-in support for scripting languages. You can embed scripts in various scripting languages into your Java applications, passing parameters, evaluating expressions, and retrieving results. And you can do it all pretty seamlessly.

First of all, you obtain a new ScriptEngine object from a ScriptEngineManager, as shown here:

ScriptEngineManager manager = new ScriptEngineManager();


ScriptEngine engine = manager.getEngineByName("js");

Each scripting language has its own unique identifier. The "js" here means you're dealing with JavaScript.

Now you can start having some fun. Interacting with a script is easy and intuitive. You can assign scripting variables using the put() method and evaluate the script using the eval() method,. which returns the most recently evaluated expression processed by the script. And that pretty much covers the essentials. Here's an example that puts it all together:

engine.put("cost", 1000);
String decision = (String) engine.eval(
"if ( cost >= 100){ " +
"decision = 'Ask the boss'; " +
"} else {" +
"decision = 'Buy it'; " +
"}");
assert ("Ask the boss".equals(decision));

You can do more than just pass variables to your scripts— you can also invoke Java classes from within your scripts. Using the importPackage() function enables you to import Java packages, as shown here:



        engine.eval("importPackage(java.util); " +
                    "today = new Date(); " +
                    "print('Today is ' + today);");

Another cool feature is the Invocable interface, which lets you invoke a function by name within a script. This lets you write libraries in scripting languages, which you can use by calling key functions from your Java application. You just pass the name of the function you want to call, an array of Objects for the parameters, and you're done! Here's an example:



        engine.eval("function calculateInsurancePremium(age) {...}");
        Invocable invocable = (Invocable) engine;
        Object result  = invocable.invokeFunction("calculateInsurancePremium",
                                     new Object[] {37});

You actually can do a fair bit more than what I've shown here. For example, you can pass a Reader object to the eval() method, which makes it easy to store scripts in external files, or bind several Java objects to JavaScript variables using a Map-like Binding object. You can also compile some scripting languages to speed up processing. But you probably get the idea that the integration with Java is smooth and well thought-out.

前幾天好不容易下到了JDK6mustang，今天恰好有時間升級了一下Netbeans默認的JDK版本。這里簡單的說明一下升級的方法。如果我 們不修改Netbeans的屬性，需要在JavaPlatform manager中加入另一版本的類庫。新建工程后如果要修改類庫，還需要修改項目的類庫屬性，現在通過修改默認的JDK類庫，便可方便很多，更不需要重新 安裝NB。

我的NB裝在D盤中，可以在該路徑找到文件D:\Netbeans-5.5\etc\Netbeans.conf，我們將原有的默認類庫netbeans_jdkhome="D:\Java\jdk1.5.0_07"修改為 netbeans_jdkhome="D:\Java\jdk1.6.0"便輕松的完成了升級，當然在tools-〉JavaPlatform manager〉中當然也可以將我們慣用的D:\Java\jdk1.5.0_07加入為可選用類庫。

第三步，輸入啟動類。輸入帶有 main 方法的類名

今天在sun的網站上轉了一圈，等了好幾天的Visual Web Pack終于出來了.

先介紹一下

Creates a new Visual Web Pack project containing an empty web application. This project enables you to use Visual Web Pack features like the Visual Designer to drag and drop JSF components, visual and dialog box support for binding components to data providers, and generation of Java code and Web XML files. The project uses the IDE-generated build script to build, run, and debug your project.

創建一個可視化頁面工程包 包含一個空白頁面應用程序.這個工程能讓你使用可視化開發包的各種屬性，諸如用可視化設計工具拖放JSF(java server face)組件,可視化的對話框支持將組件數據源（或者數據提供者）綁定在一起，并且生成java代碼和xml頁面文件。這一工程由集成開發環境（IDE）生成的構建腳本來構造，執行和調試你的項目。

(翻譯的不好請見諒)

還支持ajax，呵~~呵~~~。

最終裝好的效果圖:

全面支持拖放，呵呵，上次裝了一個java studio creator結果運行死慢死慢的，這一次把這一功能轉移到了netbeans挺好用，速度也不錯，我這臺筆記本都能挺過來，臺式機估計沒什么問題。

安裝時要注意的地方:

1.netbeans必須為5.5正式版本，beta版本的檢測不到。點擊進入netbeans首頁

2.下載JDK 5_60或者以后的版本我用的是JDK 5_09版本，安裝的時候最好不要把原來的卸載，有時候老程序不認新的JDK。點擊進入JDK下載頁面

點擊這里進入Visual Web Pack 的下載頁面。

October 20, 2006 - Anyone who believes college students today are lacking in initiative, creativity, or work ethic should take a close look at the recent accomplishments of a team of students at the Ecole de Technologie Superieure (ETS) in Montreal, Quebec. Over the past three years, this team of 12 has been heads-down working on the mechanical design, electrical system, and Java™ control and navigation software for an AUV—a submarine—and preparing it for the International Autonomous Underwater Competition sponsored by the Association for Unmanned Vehicles Systems International (AUVSI) and the Office of Naval Research (ONR) in San Diego, California.

SONIA Team Click here for more images

For no college credits, no pay, and no guarantee of success, the ETS team designed and built an AUV that could meet the complex and demanding mission requirements of the competition. Detailed in an 18-page document, these requirements included the ability to autonomously pass through a gate, detect a flashing light, find and connect with a docking station, locate a pipe and drop material into a bin—all underwater and with no communication with the team.

The submarine is called SONIA, which stands for Système d’Opérations Nautiques Intelligent et Autonome, and is just over one meter long, with a dry weight of 20 kg and a unique box-shaped design. It is equipped with sensors and two color video cameras. Navigation data input is provided by a compass and two gyroscopes as well as active and passive sonar arrays.

SONIA outperformed all but two of the 21 entries in the student competition, securing a place for ETS on the podium for a fourth year in a row. With an overall budget of just $15,000 U.S. (provided by ETS and a variety of corporate sponsors), the ETS team scored higher than teams with six-figure budgets. The competition was won by the University of Florida, but the ETS team came out ahead of renowned engineering schools such as MIT, Georgia Tech, and Virginia Tech.

Innovative Design, Expert Software Engineering

Two of the characteristics that set SONIA apart from competitors were its innovative box-shaped design and the sophistication of its core software systems.

SONIA underwater Click here for more images

The ETS team’s expertise with Java software proved a decisive advantage. Martin Morissette, software team leader of the SONIA team, is currently entering his third year in software engineering, and recently completed a six-month internship at Sun Labs, where he worked on the “Squawk VM,” a small J2ME™ virtual machine (VM) written almost entirely in Java. The Squawk VM provides the ability to run wireless transducer applications directly on the CPU without any underlying OS, saving overhead and improving performance.

“I learned a great deal during my time with Sun Labs that was extremely useful in the development of the navigation software for SONIA,” said Morissette. “The fact is, Java is an excellent programming language for robotics. All schools teach Java, so everyone on the software team knows how to use it. It’s object-oriented; it’s portable so it runs on Macs, PCs, Linux, whatever; it’s very efficient so we don’t have to worry about memory management; and there are lots of APIs available. And if you know how to write your applications properly, it can be very fast.”

The ETS team used Java for mission control and SONIA’s control systems, Java Management Extensions (JMX) for management, and a Java 3-D Simulator to simulate a broad range of mission scenarios. The team is now investigating the possibilities of Real-time Java, introduced at this year’s JavaOne Conference, for AUV and other robotics applications.

Consensus Building and Peer Review

According to Mr. Mercier, teamwork was every bit as important as technology in the ETS team’s success. “I can’t stress strongly enough that our ability to work together was the key to our success in the competition,” he said. “This is not about 12 individuals working on separate tasks by themselves. Every step of the way, we worked as a team and built consensus, so in the end everyone learned more. And that’s what this is really all about.”

For example, each software change was subject to peer review. All team members would receive an e-mail containing the previous version of the software, the new version incorporating a proposed change, and the rationale behind the change. Far from slowing the process down, the peer review concept got more team members more actively engaged, and ultimately resulted in far higher quality, according to Mr. Mercier. These peer reviews also ease the integration of new team members. Being a volunteer based project, volunteers come and go on a regular basis.

At the same time, the team shared tips and tricks with peers at other educational institutions. “This is more of a friendly rivalry than a dog-eat-dog competition,” said Tennessee Carmel-Veilleux, electrical team leader of the SONIA team. “We like to exchange information with some of the other teams, keep in touch with them. Who knows—we may all be working together some day.”

In recognition of the team’s willingness to work with other teams, and for achievements at the Unmanned Underwater Vehicle Competition, Felix Pageau, team captain, won the Andy Estabrook Award for "initiative and vision in the unmanned underwater systems.” Given for the first time to a student, the award was presented by the Lindbergh Chapter, San Diego, CA, of the AUVSI. Andy Estabrook was a pioneer in unmanned robotics and this award was created to honor his accomplishments in the advance of unmanned systems technology.

What’s next for the ETS team? The team itself is growing rapidly, thanks in part to the success at this year’s competition. The team leaders now find themselves in management roles as the team’s ranks have swollen to 34. “We’re going to compete again next year, and we’re going to focus on making our software more stable, more reliable, and faster,” said Mr. Morissette. In the mean time, the team leaders will be presenting their work at a variety of conferences worldwide—from Florida and Washington D.C. to Cologne, Germany.

And when will they get around to more traditional college activities such as frat parties and beer runs? “Probably never,” said Mr. Mercier. “We’re geeks. We’re doing what we love.”

For more information:

• SONIA website: http://sonia.etsmtl.ca
• Project Squawk (Java implementation of Project SunSPOT):http://research.sun.com/projects/squawk/
• Real-Time Specification for Java (RTSJ): http://www.rtsj.org
• Association for Unmanned Vehicle Systems International (AUVSI) http://www.auvsi.org/
• AUVSI Lindbergh Chapter: http://www.sd-auvsi.org/index.html

(2006年5月25日訊)　Sun Microsystems公司發布了一個具有革命性的新的文檔系統Solaris ZFS 1.0，它提供了多項突破性的功能，包括公共管理任務的自動化、保護數據免受非法行為的侵害，以及提供實際上無限的縮放能力。Solaris ZFS 1.0將作為我們這個星球上最先進的操作系統Solaris 10 OS的下一個商業版本的一個組成部分在今年6月份對外正式提供。此外，Solaris 10 OS的最新版本Solaris 10 6/06將先進的前攝性自愈技術和聯網技術，與對PostgreSQL開源數據庫的全面支持結合起來，進一步強化了Solaris 10 OS作為宿主高性能的關鍵數據庫解決方案的首選平臺的地位。

作為世界上最先進的文檔系統，Solaris ZFS可以自動檢測和修改細小的數據錯誤或遭遇意外侵害的數據，以提供信息的完整性。Solaris ZFS還因?yàn)椴恍枰碜诠芾砥鞫蟠蠛?jiǎn)化了數據的管理，而卷宗管理器是今天數據管理事務中最耗時、最費錢的部分。例如，今天，一項典型的系統管理任務可能 需要40多分鐘來完成，但是采用Solaris ZFS，僅僅需要幾秒鐘的時間，且沒有系統宕機的危險，從而大大降低了數據管理的成本費用。此外，Solaris ZFS還是世界上第一個128位的文檔系統，這使系統具有了實際上無限的數據容量。Solaris ZFS提供的先進的縮放能力和管理能力，使它成為許許多多傳統UNIX?文檔系統的理想替代品。

Solaris是宿主高性能數據庫的杰出平臺。最近，Oracle指名Solaris 10 OS作為其開源64位開發和部署環境的理想平臺。現在，Sun還將開源PostgreSQL數據庫集成在Solaris 10 OS的最新版本內，對PostgreSQL數據庫提供全面支持。Sun與PostgreSQL社團開展合作，讓他們采用Solaris 10 OS提供的各種先進技術，如前攝性自愈技術、Solaris分區特性和Solaris動態跟蹤能力(DTrace)等。

“面對不斷增長的依順性要求，今天的數據量每9～12個月就要翻番，但今天的文檔系統還植根在上世紀70年代的技術之中，”Sun公司主管系統軟件部的 副總裁Tom Goguen說，“Solaris ZFS從設計之初就是要迎接今天數據管理的挑戰，它的預期壽命是20～30年。這一128位的文檔系統所能存儲的自愈數據是今天已有文檔系統的160億 倍，同時還大大簡化了卷宗的管理。Solaris ZFS將是今年內發布的最重要的創新技術之一。”

Solaris 10是我們這個星球上最先進的操作系統，它可在650多款SPARC和x64/x86平臺上運行，獲得來自獨立軟件廠商的2,200多種應用程序的支持。 其無與倫比的功能性和硬件平臺的支持，加上它所提供的行業唯一的應用兼容性保證，加快了Solaris 10 OS在全球的應用步伐，目前Solaris 10 OS的注冊許可數已超過450萬。

具有革命性的新的文檔系統技術

Solaris ZFS 1.0具有任何其他商用文檔系統技術所無法匹敵的優異性能。客戶可以從Solaris ZFS技術中享用到先進的數據完整性技術、使用和管理的簡易性、難以置信的高性能，以及實際上無限的縮放能力。

• 端到端的數據完整性―― 基于校驗和與事務性寫入復制(copy-on-write)機制的突破性的結合，Solaris ZFS可提供滿足CIO和系統管理員要求的數據準確性。Solaris ZFS擁有先進的錯誤檢測機制，能識別被損壞的數據，并將之在運行中修改過來。例如，鏡像的一側被意外地重寫，ZFS可以對之檢測、修補和恢復，且完全不 干擾服務的進行。
• 簡化的管理――Solaris ZFS提供了一種基于共享的架構模式，使所有的共享數據和功能納入虛擬內存管理。Solaris ZFS文檔系統可以自動地增長或收縮，而無需占據額外存儲空間的卷宗管理器。Solaris ZFS還提供了在任何時間點上對文檔系統進行瞬間快照的能力，這就大大節約了一般系統管理員手工恢復文檔所花費的時間和資源。
• 性能的巨大提升――Solaris ZFS的架構設計有助于提高速度。寫入復制的設計可將隨意寫入轉變?yōu)榭焖龠B續寫入。其輸入/輸出(I/O)帶寬在有數據存儲時可自動加大。無論工作量如 何，多種字區尺寸會自動做出最佳配合。智能化的預取感式讀取可加快運行速度。而且，它的高級的、可擴展的I/O子系統設計采用了記分板式的流水線操作和依 賴性時序安排，同樣提供了極大的性能提升。
• 無限的數據容量――Solaris ZFS是世界上第一個128位文檔系統，具有實際上無限的數據容量。


Sun公司簡介

一個獨具特色的理念――“網絡就是計算機”，指引著Sun各項技術的發展，為全球各個重要的市場增添活力。Sun共享創新和創建社團的思想體系處于新 一代網絡計算－參與時代－的最前沿。Sun的足跡遍及全球100多個國家和地區，其互聯網的網址為http://www.sun.com。Sun公司的中 文網址為http://www.sun.com.cn。

ZFS是第一個128位的文件系統，同時ZFS又被Sun Microsystems稱作史上最后一個文件系統。因?yàn)檫@個文件系統含有多項創新技術，不僅成功地解決現有文件系統的問題和陋習，而且前瞻性地考量了未 來對存儲空間的需求，單個文件系統可以達到256 quadrillion（264） Zettabytes（221）。 ZFS不僅符合POSIX文件系統的標準，而且提供了許多高級功能比如：Quota(配額)，Reservation(預留), Compression(壓縮)， Snapshot(快照)，Clone（克隆）等。如果你還在堅持使用現有32位或者64位的文件系統，如果你還在“痛并不快樂著”地用著各式各樣的 Volume Manager，那就很值得看看這里列出的使用ZFS的十條理由。

1. 再也不需要fsck, scandisk

不管你是在用Linux，UNIX還是Windows，相信大家都有過類似的體會：當系統意外斷電或者非法關機，系統重起后發現文件系統有 inconsistent的問題，這時 候就需要fsck或者scandisk 來修復，這段時間是非常耗時而且最后不一定能夠修復成功。更糟糕的是，如果這是一臺服務器需要做fsck的時候，只能offline（下線），而且現有應 用往往都是大硬盤，相應fsck修 復時間也很長，這對許多使用該服務器的用戶來說幾乎不能忍受的。而使用ZFS后大家可以徹底拋棄fsck這種工具，因?yàn)閆FS是一個基于COW（Copy on Write）機制的文件系統。COW是不會對硬盤上現有的文件進行重寫，保證所有硬盤上的文件都是有效的。所以不會有這種inconsistent的概 念，自然就不需要這種工具了。

2. 管理簡單

　　ZFS作為一個全新的文件系統，全面拋棄傳統File System + Volume Manager + Storage的架構，所有的存儲設備是通過ZFS Pool進行管理，只要把各種存儲設備加 入同一個ZFS Pool，大家就可以輕松的在這個ZFS Pool管理配置文件系統。大家再也不用牢記各種專業概念，各種命令newfs, metinit及各種Volume Manager的用法。在ZFS中我們只需要兩個命令，zpool(針 對ZFS Pool管理)和zfs(針對ZFS文件系統的管理)，就可以輕松管理128位的文件系統。舉個例子，我們經常會遇到系統數據增長過 快，現有存儲容量不夠，需要添加硬盤，如果依照傳統的Volume Manager管理方式，那我 們需要預先要考慮很多現有因素，還要預先根據應用計算出需要配置的各種參數。在ZFS情況下，我們的系統管理員可以徹底解放，再也不需要這種人為的復雜 考慮和計算，我們可以把這些交給ZFS，因?yàn)閆FS Pool會自動調節，動態適應需求。我們只需一個簡單的命令為 這個ZFS Pool加入新的硬盤就可以了：

zpool add zfs_pool mirror c4t0d0 c5t0d0

　　基于這個動態調節的ZFS Pool之上的所有的文件系統就可以立即使用到這個新的硬盤，并且會自動的選擇最優化的參數。

　　而且ZFS同時也提供圖形化的管理界面，下面是一個ZFS圖形化管理的一個截屏：

[attachment=2119]

3. 沒有任何容量限制

ZFS（Zettabyte File System）文件系統就如其名字所預示，可以提供真正的海量存儲，在現實中幾乎不可能遇到容量問題。在現有的64位kernel（內 核）下，它可以容納達到16 Exabytes(264)大小的單個文件，可以使用264個存儲設備，可以創建264個文件系統。

4. 完全保證 數據 的正確和完整

由于ZFS所有的數據操作都是基 于Transaction（事務），一組相應的操作會被ZFS解 析為一個事務操作，事務的操作就代表著一組操作要么一起失敗，要么一起成功。而且如前所說，ZFS對 所有的操作是基于COW（Copy on Write）， 從而保證設備上的數 據始終都是有效的，再也不會因?yàn)橄到y(tǒng)崩潰或者意外掉電導致數據文件的inconsistent。

還有一種潛在威脅 數據的可能是來自于硬件設備的問題，比如磁 盤，RAID卡的硬件問題或者驅動bug。現有文件系統通常遇到這個問題，往往只是簡單的把錯誤數據直接交給上層應用，通常我們把這個問題稱作 Silent Data Corruption。而在ZFS中，對所有數據不管是用戶數據還是文件系統自身的metadata數 據都進行256位的Checksum（校 驗），當ZFS在提交數據時會進行校驗，徹底杜絕這種Silent Data Corruption情況。

5. 提供優異 性能和擴展性

　　和傳統File System + Volume Manager + Storage架構不同，ZFS則是直接基于存儲設備提供所有的功能，因此有自己獨有的創新特性，性能自然非比尋常。

  * Dynamic Striping vs. Static Striping

由于ZFS是基于COW和一個全局動態的ZFS Pool，任何一次寫 操作，都是對一塊新數據塊（Block）的一次寫操作。ZFS從ZFS Pool中動態挑選出一個最優的設備，并且以一個transaction（事 務）線性寫入，充分有效地利用了現有設備的帶寬，我們把這個特性稱為Dynamic Striping。而相對應的Static Striping則是傳統文件系統所使用的方式，Static Striping需要管理員預先對這組Stripe進行正確地計算人為 設置，而且如果加入新的設備則需要再次人為的計算和設置，更為嚴重的是如果人為計算錯誤，則會直接影響系統的性能。而在使用Dynamic Striping這種特性之后，我們根本不需要人為介入，ZFS會自動調整，智能的為你 提供最佳的設備，最快的操作方式。

  * 支持多種 大小的數據塊（Multiple Block Size）

　　ZFS支持多種大小的數據塊定義，從512字節到1M字節。和傳統文件系統往往都是固定大小數據塊不同，ZFS則是可以動態的根據不同 大小的文件進行計算，動態的選擇最佳的數據塊。

因?yàn)椴煌笮?shù)據 塊，直接影響到實際使用硬盤容量和讀取速度。如果使用較小的數據塊，存儲文件所導致的碎片則較少，讀寫小文件更快一些，但是會導致需要?jiǎng)?chuàng)建更多的 metadata，讀寫大文件則會更費時。如果使用較大的數據塊，使用的metadata較少，更利于讀寫大文件，但是會導致更多的碎片。ZFS根據實際 調查現有文件使 用的情況，分析出一個選擇數據塊大小的算法，動態的根據實際文件大小確定最佳的數據塊。所以ZFS是 非常智能的，在不需要系統管理員介入，就可以得到一個自我調優的結果。當然ZFS也支持用戶對單個文件或者整個文件系統 所使用的數據塊大小的自定義設置。

  * 智能預讀取（Intelligent Prefetch）

　　多數的操作系 統都 有這種將數據預先讀取的功能，而ZFS則是建立在文件系統上直接提供的一種更加智能的數據預讀取功能。它不僅可以智能地識別出多種讀取模式， 進 行提前讀取數據，而且可以對每個讀取數據流進行這種預讀取智能識別，這個對許多流媒體提供者來說是件非常好的事情。

　　在擴展性上，和現有文件系統多是基于一個受限的靜態模型不同，ZFS是采用ZFS Pool這個動態概念，它的metadata也是動態，并且讀寫操作都是可并行的，并且具有優先級概念，所以即使在大數據量，多設備的情況下仍可以保證性能的線性增長。

6. 自我修復功能

  * ZFS Mirror 和 RAID-Z

傳統的硬盤Mirror及RAID 4，RAID 5陣列方式都會遇到前面提到過的問題：Silent Data Corruption。如果發生了某塊硬盤物理問題導致數據錯誤，現有的Mirror，包括RAID 4，RAID 5陣列會默默地把這個錯誤數據提交給上層應用。如果這個錯誤發生在Metadata中，則會直接導致系統的Panic。 而且還有一種更為嚴重的情況是：在RAID 4和RAID 5陣列中，如果系統正在計算Parity數值，并再次寫入新數據和新Parity值的時候發生斷電，那么整個陣列的所有存儲的數據都毫無意義了。

在ZFS中則提出了相對應的ZFS Mirror和RAID-Z方式，它在負責讀取數據的時候會自動和256位校驗碼進行校驗，會主動發現這種Silent Data Corruption，然后通過相應的Mirror硬 盤或者通過RAID-Z陣列中其他硬盤得到正確的數據返回給上層應用，并且同時自動修復原硬盤的Data Corruption 。

  * Fault Manager

在Solaris 10中，包含 一個ZFS診斷引擎和Solaris的 Fault Manager（這也是Solaris 10的 另一個新特性）交互，可以實時地診斷分析并且報告ZFS Pool和存儲設備的錯誤，用戶可以通過Fault Manager及時得到一個非常友善的消息。這個診斷引擎雖然不會采取主動的行為去修復或者解決 問題，但是會在消息中提示系統管理員可采取的動作。類似下面一個ZFS報錯消息，其中REC-ACTION就是建議采取的動作：

SUNW-MSG-ID: ZFS-8000-D3, TYPE: Fault, VER: 1, SEVERITY: Major

EVENT-TIME: Fri Mar 10 11:09:06 MST 2006

PLATFORM: SUNW,Ultra-60, CSN: -, HOSTNAME: neo

SOURCE: zfs-diagnosis, REV: 1.0

EVENT-ID: b55ee13b-cd74-4dff-8aff-ad575c372ef8

DESC: A ZFS device failed. Refer to http://sun.com/msg/ZFS-8000-D3 for more information.

AUTO-RESPONSE: No automated response will occur.

IMPACT: Fault tolerance of the pool maybe compromised.

REC-ACTION: Run ’zpool status -x’ and replace the bad device.

7. 安全

　　在安全上，ZFS支持類似NT風格NFSv4版的ACL（讀取控制列表）。而且前面所提到的256位驗證碼，用戶可選擇多種驗證方式，包括SHA-256驗證算法，從而在物理存儲單元級別上保證數據的安全性。

8. 超強功能

ZFS作為“最后一個文件系統”，涵蓋了基本的文件系統和Volume管理的功能，同時 一并提供許多企業級別的超強功能：Quota(配額)，Reservation(預留), Compression(壓 縮)， Snapshot(快照)，Clone（克隆）。并且速度非常快。有了這個文件系統，大家再也不需要任何Volume Manager了。

9. 兼容性

ZFS是一個完全兼容POSIX規范的文件系統，所以處于上層的應用程序是完全不受影響。ZFS也提供一個Emulated Volume模塊，可以把任何一個ZFS文件系統作為普通的塊設備使用。同時ZFS也可以使用基于Volume Manager構建的Volume作為存儲設備單 元。這樣在不需要修改應用程序，不修改已有文件系統下，給了大家最大的自由度去獲得ZFS提供的各 種特性。

10. 開源

　　ZFS是Sun Microsystems公 司作為OpenSolaris的一個開源項目運作并且完全免費使用，點擊這里(http://www.opensolaris.org/os/community/zfs/source/) 可以直接瀏覽到ZFS的代碼。 這就代表著我們不僅同時可以享受商業公司的高質量，也可以獲得開源模式的優點。

雖然目前只有Solaris支持該文件系統，但是這種開源的模式必定會促進更多基于ZFS的應用。現在已經有國外開發者正在將ZFS移植到Linux和 Mac OS上來。如果想要體驗一下ZFS，由于目前它和Solaris 10綁定在一起，所以需要下載最新版的Solaris 10 6/06 (http://www.sun.com/software/solaris/get.jsp)。

參考:

Solaris ZFS Administration Guide: http://docs.sun.com/app/docs/doc/819-5461?l=zh&q=ZFS

Solaris 10 Zone FAQ: http://www.sun.com/software/solaris/faqs/zfs.xml

Automatic Performance Tuning in the Zettabyte File System: http://tesla.hpl.hp.com/self-manage03/Finals/henson-self-tune.pdf
